Solis Hybrid Inverter 5 kW Single Phase | RHI-5K48ES-5G
The Solis RHI-5K-48ES-5G is a versatile 5kW hybrid solar inverter designed for residential use, supporting both on-grid and off-grid operations. It handles a maximum PV input of 8kW with a 600V upper limit and operates within a 90-520V MPPT range. Compatible with Li-ion and Lead-acid batteries (42-58V range), it offers a 5kW charge/discharge capacity. The inverter outputs 220/230V AC at 50/60Hz with a rated current of 22.7A. Boasting a peak efficiency of 97.5% and rapid 20ms backup switching, it features smart energy management, RS485 communication, optional Wi-Fi, and comprehensive protection mechanisms. Its fanless, IP65-rated design ensures quiet operation and outdoor durability, all within a compact 333x505x249mm frame weighing 18.3kg.
Brand: Solis |
Phases: 1-Phase |
Inverter type: Hybrid |
Inverter Size: 5.0Kw |
No. of MPPT: 2 |
Max Isc per MPPT: 17.2 A |
Rated Output Current: 22.7 A |
Max Recommended PV Power: 8000 W |
Start-up Voltage: 120 V |
