Sigenergy CT Meter (Sigen Power Sensor TP-CT120-DH)
Sigen Power Sensor Three Phase External CT DH
The seamless integration of the Sigen Power Sensor with Sigenergy devices requires no setup.
Within the SigenStor 5-in-1 Energy Storage System, this energy sensor plays a crucial role. Sigenergy's ESS effortlessly combines elements such as the PV inverter, Battery Power Conversion System (PCS), EV DC Charger tailored for electric vehicles, Battery Pack, and the Energy Management System (EMS). No additional configuration is necessary for the smooth collaboration of these components.
Key features :
• 1% high-accuracy power detection for precise control
• LCD real-time info display, easy to operate and check
• Integrates smoothly with Sigenergy devices, no need for setup
• Top class 100 A direct connection in Power Sensor with built-in CT
• Support export/import limitations and ready for AI evolving
• 100 ms data refresh rate, instantaneous data feed
| Brand: Sigenergy |
| Maximum Input voltage: 480V AC |
| Grid Connection Type: 3P3W/3P4W |
| Voltage Measurement Accuracy: 0.5% |
| Current Measurement Accuracy: 0.5% |
| Power Measurement Accuracy: 1% |
| Frequency Measurement Accuracy: 0.2% |
| Communication Interface: RS485 |
| No of CT: 3 |
| Maximum Operating current of CT: 120A |
